W01-M58-6160 Firestone Industrial Air Actuator 1/4 BSP Convoluted Type Air Spring

جزئیات محصول:

محل منبع:	گوانگدونگ، چین
نام تجاری:	GUOMAT
گواهی:	ISO/TS16949, ISO9001
شماره مدل:	2B6160

پرداخت:

مقدار حداقل تعداد سفارش:	1
قیمت:	$59.9-$69.9/PC
جزئیات بسته بندی:	جعبه کارتن قوی یا به عنوان نیاز مشتری
زمان تحویل:	5-8 روز کاری
شرایط پرداخت:	L/C ، D/A ، D/P ، Western Union
قابلیت ارائه:	1000 قطعه در هفته

مخاطب

توضیحات محصول جزئیات

نام مدل:	چشمه هوای لاستیکی	بسته حمل و نقل:	کارتن
علامت تجاری:	گواتر	تابع:	لرزش را کاهش دهید
پیچیدگی:	یک نوع پیچیده	MOQ:	4 عدد
سنگ فرش:	W01-M58-6160	سبک:	سبک 25
برجسته کردن:	Firestone Industrial Air Actuator,1/4 BSP Air Spring,Convoluted Type Air Spring , 1/4 BSP Air Spring , Convoluted Type Air Spring

W01-M58-6160 Firestone Industrial Air Actuator 1/4 BSP Convoluted Type Air Spring

Product Introduction

Project	Description
Brand	GUOMAT
Model	2B6160
Material	Premium rubber and reinforced steel: Rubber components offer excellent flexibility and fatigue resistance; metal components are rust-proofed for long service life.
Structure Type	Double Convoluted
Warranty	1 year: We provide a solid guarantee for product quality.
Packaging	Standard brown cardboard box: Ensures good protection of the product during transportation; neat packaging.
Minimum Order Quantity	4 pieces

OE Manufacturer Number

Firestone Style Number: Style 25
Firestone Number: W01-M58-6160
Firestone Number: W01 M58 6160
Firestone Number: W01M586160
Firestone Number: WO1-M58-6160
Firestone Number: WO1 M58 6160
Firestone Number: WO1M586160
Blind nuts, 1/4 BSP
Firestone W01-M58-6160 / W01 M58 6160 / W01M586160
Socket head aluminum bead rings (bolts, nuts, washers not included-use M6 cap screws)
Firestone W01-358-0030 / W01 358 0030 / W013580030
Rubber bellows only (no girdle hoop)
Firestone W01-358-0025 / W01 358 0025 / W013580025

Force Table

Assembly Height(mm)	Volume@7 BAR (cu cm)	EFF Area@7 BAR(cm sq)	kN @3BAR	kN @4BAR	kN @5BAR	kN @6BAR	kN @7BAR
140	14081	847	23.26	32.31	40.96	50.59	59.29
130	13097	922	25.78	35.46	44.84	55.17	64.52
120	12133	982	27.78	37.99	47.98	58.85	68.74
110	11058	1033	29.48	40.18	50.67	62.00	72.34
100	10008	1075	30.83	41.97	52.85	64.53	75.23
90	8840	1110	31.99	43.53	54.73	66.70	77.72
80	7704	1139	32.96	44.81	56.25	68.45	79.72
70	6445	1162	33.79	45.85	57.48	69.86	81.34
